1'' grinding ball price

Size: 20mm-150mm

Material: B2, B3, B6, 45#, 40Cr, 42CrMo, 65MN, 60MN,

Uniform Hardness;

High Wear Resistance;

Low Breakage Rate;

Without loss of round;

High impact toughness;

Breakage rate: ＜1%

Annual production is over 100.000tons;

Contact Now E-Mail Telephone WhatsApp

Product Details

Grinding media forged ball manufacturer with 28 years in China, annual production capacity of 100,000 tons. products are exported to Brazil, Mexico, Ghana, Chile, Peru, South Africa, Cote d 'Ivoire, Mali, Mauritania, Ecuador, Philippines and other countries, Sign annual contracts with many mines for 3-5 years.

Free sample can be supply for test.

tupian 8 (4).jpg

Chemical composition of Grinding Ball:

Materials	C%	Si%	Mn%	P%	S%	Cr%
B2	0.70-0.85	0.17-0.37	0.70-1.00	≤0.035	≤0.035	0.4-0.6
B2-1	0.55-0.70	0.15-0.30	0.65-0.85	≤0.020	≤0.020	0.70-1.10
High Carbon B2	0.85-1.10	0.15-0.45	0.40-1.20	≤0.035	≤0.035	0.20-1.10
B3	0.58-0.66	1.70-1.90	0.68-0.80	≤0.030	≤0.030	0.78-0.90
45#	0.42-0.50	0.17-0.37	0.5-0.8	≤0.035	≤0.035	0.25max
B4	0.65-0.75	1.20-1.40	0.50-0.70	≤0.025	≤0.025	0.85-1.00
B6	0.75-0.90	0.17-0.37	0.8-1.02	≤0.035	≤0.035	0.88-0.98
B6-1	0.82-0.90	0.15-0.35	0.90-1.05	≤0.020	≤0.020	0.88-0.98
BU	0.95-1.05	0.15-0.35	0.95-1.05	≤0.025	≤0.025	0.45-0.55
1090	0.90-1.10	0.17-0.37	0.60-0.90	≤0.025	≤0.025	≤0.025
42CrMo	0.38-0.45	0.20-0.40	0.50-0.80	≤0.035	≤0.035	0.90-1.20
40Cr	0.37-0.45	0.20-0.40	0.50-0.80	≤0.035	≤0.035	0.80-1.10
65MN	0.62-0.70	0.17-0.37	0.90-1.20	≤0.035	≤0.035	≤0.25
60MN	0.57-0.65	0.17-0.37	0.70-1.00	≤0.035	≤0.035	≤0.25
50MN	0.48-0.56	0.17-0.37	0.70-1.00	≤0.035	≤0.035	≤0.25

Specification of Grinding Ball:

Diameter(mm)	Diameter Tolerance(mm)	Surface Hardness(HRC)	Impact Toughness(j/cm2)
Φ20	+2， —1	＞60HRC	≥12
Φ25
Φ30
Φ40
Φ50
Φ60	+3， —2
Φ70
Φ80
Φ90
Φ100	+4， —2
Φ110
Φ120		＞58HRC
Φ130		＞58HRC
Φ140	+4， —3	＞55HRC
Φ150	+4， —3	＞55HRC
